New Models Offer High Precision and Efficiency

Kyoto, Japan – NIDEC Machine Tool Corporation announced the launch of the ZFA Series, a new line of high-precision gear grinders designed to meet global demand for advanced gear machining. The ZFA160 and ZFA260 models offer exceptional performance and efficiency for a wide range of gear sizes.

Designed for high-speed and high-precision finishing of gears, the ZFA Series features a twin-table structure and high-speed rotary performance, resulting in a significantly reduced non-machining time compared to previous models. The ZFA160 and ZFA260 also incorporate advanced features to ensure fast, stable and accurate machining, including stiffer work-table structures, grinding spindles, and dressing units.

The ZFA Series is ideal for machining gears for electric vehicles and robots, offering features like simultaneous double-tooth flank bias adjustment and low-noise machining. Additionally, the models are designed with environmental sustainability in mind, featuring a circular, filter fabric coolant tank that reduces waste generation.

As the demand for high-precision gears continues to grow, NIDEC Machine Tool is committed to providing innovative solutions that meet the evolving needs of the global market. The ZFA Series offers a combination of precision, efficiency, and sustainability, making it a valuable asset for manufacturers worldwide.

Main specifications of gear grinding machines ZFA160 and ZFA260

Specifications	Unit		ZFA160	ZFA260
Maximum work-piece diameter	mm		φ160	φ260
Process-sable module^*4	mm	Standard	1 – 4	1 – 6
		OPT	0.5 – 1.0	0.5 – 1.0
Grinding wheel external diameter	mm		φ208 – 275
Grinding wheel maximum rotating speed	min^-1		8,000
Table maximum rotating speed	min^-1		3,000	2,000
Electric source capacity	kVA		110
Machine mass	kg		15,000

*1. By installing two work-accommodating tables onto a machine, one can set up machining on one side while machining is underway on the other side.

*2. A component or material whose natural rock, etc. has been solidified with resin. This material has a low thermal conductivity, is hard to be affected by temperature change, and has a high vibration damping. In addition, unlike cast metals, there is no manufacturing process that discharges a large amount of CO₂.

*3. An index that indirectly represents the precision of a gear’s pitch circle. “O.B.D” stands for “over ball diameter.”

*4. Module: A value that represents the size of a gear’s teeth (i.e., the pitch circle’s diameter (mm) divided by the number of teeth).

###

About NIDEC Machine Tool Corporation

NIDEC Machine Tool Corporation is a global leader in innovative machine tool solutions. The company, along with NIDEC OKK, PAMA, and TAKISAWA, works collaboratively to deliver high-quality, high-efficiency machine tools that support various industries worldwide.
